PICTURE IS FOR ILLUSTRATION ONLY
Price is for One
These fittings are especially suitable for connecting plastic, rubber of soft p.v.c, silicone hoses in industrial and domestic applications.
As hoses have various wall thicknesses the size is by ID measurement of the hose.
I.E 6mm Internal diameter hose needs a 6mm (1/4") fitting.
These fittings are strong and durable.
Working Pressure: 14 bar (200 psi) Max at +20 °C
Temperature Range: -20 °C up to +110 °C (-5 °F up to +230 °F) - subject to application.
Material: Nylon 66
Assembly: Tubes dressed onto barbed tail of fitting and secured with hose clip or snap clip.
Nylon is chemically compatible with Diesel Fuel, Hydraulic Oils, Methanol, Petroleum and Sodium Hydroxide
Other Size's We Stock
| Product Code | Description |
| TF-12446944028 | 4mm x 1/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446944048 | 4mm x 1/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446945028 | 5mm x 1/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446945048 | 5mm x 1/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446945088 | 5mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446946028 | 6mm x 1/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446946048 | 6mm x 1/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446946068 | 6mm x 3/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446946088 | 6mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446948028 | 8mm x 1/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446948048 | 8mm x 1/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446948068 | 8mm x 3/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446948088 | 8mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446950048 | 10mm x 1/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446950068 | 10mm x 3/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446950088 | 10mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446950128 | 10mm x 3/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446952048 | 12mm x 1/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446952068 | 12mm x 3/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446952088 | 12mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446952128 | 12mm x 3/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446954068 | 14mm x 3/8 Inch BSPT Male Elbow Hose Fitting |
| TF-12446954088 | 14mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446954128 | 14mm x 3/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446956088 | 16mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446956128 | 16mm x 3/4 Inch BSPT Male Elbow Hose Fitting |
| TF-12446959088 | 19mm x 1/2 Inch BSPT Male Elbow Hose Fitting |
| TF-12446959128 | 19mm x 3/4 Inch BSPT Male Elbow Hose Fitting |
-
Product Code:TF-12446946028
-
Weight:0.001kg
